DETAIL
BALL DIAMETER(A) | SHANK DIAMETER(B) | SHANK LENGTH(C) | CAPACITY(LBS) | |
50mm | 7/8" | 62mm | 3500 | |
50mm | 7/8" | 62mm | 57mm flange with flats | 3500 |
50mm | 7/8" | 50mm | 3500 | |
1 7/8" | 3/4" | 52mm | 2000 | |
50mm | 3/4" | 52mm | 2000 | |
50mm | 1" | 52mm | 3500 | |
1 7/8" | 1" | 52mm | 3500 |
